Filtering EMI from Switching Power Supplies

For some time now we’ve been experiencing strange problems with the USB system inside the cube.  Somewhere along the USB path something drops the connection, either the Arduino or the Hub or the Linux box. We first tried swapping out USB cables or Hubs. We suspected the Arduinos were drawing more power then the hubs could provide so we separately power them with power supplies. Finally we started suspecting the Dimduino boxes them selves were at fault.

IMG_0196_small

Nothing seemed to provide any particular relief. Oddly the frequency of the disconnections was not isotropic and certain boards tended to cause disconnections much more frequently (every few minutes) then others. Swapping out the dimduino boxes or the arduinos didn’t affect this though, which was suspicious. Finally it dawned on me that the PowerSupplies that power the Lights must be at fault because that was the only element we hadn’t yet tried to change. Sure enough, analysis of the freuquency of the dropped connections with whether or not the lightbox was powered by a new style power supply (an IP67 compliant, waterproof switching powersupply) or an ATX powersupply was conclusive. The new switching powersupplies were in fact at fault. Removing them all and powering everything off ATX PSUs fixed all the disconnection problems overnight.

So far so good. Now, however the cube was running on a single PSU per box, i.e. our redundancy was compromised (we only just had enough ATXes to power each box with one PSU). Thus I’ve been trying to figure out what the issue is with these new PSUs and if there’s a cheap fix.

I hooked them up to my oscilloscope and it was pretty clear that these new power supplies are switching power supplies but it appears of poor quality. Unlike an ATX which gives perfectly smooth power there’s a lot of high frequency noise on the output.

IMG_0192

Measuring Vout and V1 (Fig A) shows some interesting patterns: B) Vout has a 83KHz beat of about 2V magnitude and a faster superimposed frequency in the Mhz range decaying exponentially like a damped oscillator after each 83Khz beat.

C) V1, between 0V output and Ground, is clearly carrying a 60Hz mains hum and a faster ripple on top of that, which resembles the ripple in B). The 60Hz oscillation has a large magnitude (like 60V or so) but clearly very high impedance (you dont get zapped when you touch it and barely any current flows if you connect 0V to Ground, but the 60Hz oscillation on both 0V and 12V disappears completely).

These oscillations make the whole cube circuitry swing like hell, and sends out a ton of EMI and RF everywhere. I can pick up the Mhz signal using just a piece of wire in the air. No wonder the USB was struggling.

diagram1 The two solutions I arrived at, empirically are shown in D) and E).
One involves a resistor and a capacitor and the other has an additional direct resistor.
Both smooth out Vout ( B) ) quite a lot, though not completely and V1 also looks quite a bit better but also not perfect. E) i think works a weeny bit better, but its all comparable. Some spike voltages remain on V1 that I just can’t get rid of it seems. Vout is now pretty smooth. Adding another cap between Out+ and Out- doesnt help to remove any residual noise. Nor does adding Y caps for the +12V line (from +12V to GND ).

emifilter
I found a nice article on Switching PSUs and EMI which suggests a more elaborate but straightforward circuit with additional caps and particularly in-series inductors. Makes sense, the inductors will further resists the AC going forward. I’m tempted to try it but maybe what I cooked up is sufficient (it certainly appears to be, empirically speaking).

Also I talked to a knowledgeable person at ORDcamp this weekend who suggested using higher voltage caps should not only make things safer but also help absorb more of the 60Hz hum and the RF.

If all of this doesn’t help the next step is clearly to add in series inductors but this is a slightly bigger undertaking and begs the question if it wouldn’t be better to just move to a different PSU. Would be a shame though to toss the 14  $70 PSUs that in all other ways are absolutely perfect.

, ,

1 Comment

Creating a Ubuntu LiveCD using VirtualBox and Remastersys

For a project I’m working on I wanted to create a bootable LiveCD that would start X, start Chrome and go to a particular address.

First I playe around a little bit with Slax. Its impressive in terms its ability to create cutom LiveCD .iso files on the fly by cobbling it together from components online and just download an ISO image & done. Its cool, works out of the box and I was able to get X running with Fluxbox and Chrome 12 in a 160MB .iso (!). But Chrome 12 turned out to be buggy, i wanted 16 at least. Slax is based on slackware and thus doest seem to natively support .deb or .rpm packages. You can kind of work around that by using provided tools such as rpm2lzm etc but it seemed hacky. When I tried installing it i ran in to a ton of dependency problems. I also wanted more customability so I looked for a way to set up a linux virtual machine, customize it to my hearts content and then somehow zap the whole thing into a bootable ISO format. This is exactly what Remastersys does.

So what I ended up doing is this:

  1. Start with VirtualBox. It’s a virtual machine tool for MacOS (and others). I’ve not worked much with virtual machines but this absolutely rocks. You just create a virtual machine, tell it how much RAM, HDD, etc you want. You can manipulate all the IO devices easily. Just download an .iso file or link the CDROM drive to the real drive in your computer and off you go.You can also make snapshots of the entire state machine and thus installation and configuration are way easier, if you’re ever unsure. And believe me I made a lot of mistakes along the way.So create a virtual box. Give it +500MB  RAM and 5GB HDD.
  2. Download mini.iso from Ubuntu. Link this file to your virtual CDROM drive and start the machine. Ubuntu will boot a minimal LiveCD system and allow you to install a Ubuntu system on your virtual Drive. Instead of selecting individual packages I chose the “Xubuntu” preconfig.
  3. Remove the virtual CD and reboot. Using Firefox download Chrome 16 (or later). You should download the .deb package since Ubuntu is derived from Debian. Set the user to “username” and give it a password. You’ll need this in the following setup process.
  4. Open a terminal. Navigate to where the .deb file got downloaded to and do:
     sudo dpkg –i google-chrome*.deb

    This will likely throw some unsatisfied dependencies.
    Resolve them by using

    sudo apt-get install [package name ]

    Then re-issue the dpkg command :

    sudo dpkg –i google-chrome*.deb

    Start chrome with

    /opt/google/chrome/chrome

    Set up chrome the way you like. In my case I had to install a plugin and configure it.

  5. Next install remastersys.
    First you need to get a security key from remastersys and then register their site in /etc/apt/sources.list so that apt-get will know where to get it from. Simply do:
    wget http://www.remastersys.com/ubuntu/remastersys.gpg.keysudo apt-key add remastersys.gpg.key Then, add the following line that corresponds to your version of Ubuntu to your /etc/apt/sources.list

    #Remastersys Lucid
    deb http://www.remastersys.com/ubuntu lucid main
    #Remastersys Maverick
    deb http://www.remastersys.com/ubuntu maverick main
    #Remastersys Natty
    deb http://www.remastersys.com/ubuntu natty main
    #Remastersys Oneiric
    deb http://www.remastersys.com/ubuntu oneiric main

    In my case it was the last one.

    Now you just need to do:

    sudo apt-get update
    sudo apt-get install remastersys
  6. Do a ‘df’, and you’ll see your system is currently about 2.2GB (at least it was in my case).  This, compressed, will make an .iso file that is about 750MB, which unfortunately doesn’t fit on a CD. So to get the final LiveCD ISO to be as small as possible we want to loose all the weight we don’t need. This was slightly tricky and required a few attempts to get right. It was important to preserve all Chrome functionality, auto Xstart capability and all sound playing ability. I definitely screwed up each of these at least once.

    So therefore the next step is to

    Make a snapshot of the Virtual Machine using VirtualBox

  7. Now, go and do
    sudo apt-get install aptitude
    sudo aptitude

    I went in an removed a lot of stuff, all window managers, firefox, editors, graphics programs, documentation, etc etc. All sorts of crap you don’t need.

    You need to make sure to not remove anything that what you need is dependent on though! I did this largely by trial and error. I’d choose enough packages to loose about 200MB (Aptitude will tell you in the upper right hand corner how much its removing) and let you know about dependenceies. I’d then hit ‘g’ remove the packages, quit aptitude, reboot the machine (sudo reboot) and see if chrome and X and sound still worked. If so I’d make another snapshot on VirtualBox and continue, if not I’d go back to the last snapshot and try again.

    Apparently I needed to preserve certain parts of Gnome and importantly GDM. Also ALSA sound drivers need to stay obviously. There’s a lot of stuff that seems like it’s not needed but essential parts are dependent on it. Anyway, I managed to reduce the system size to about 1.35 GB, which awesomely reduces down to an .iso of about 450MB!

  8. Ok, so I wanted the system to just boot straight into Chrome running in X, alone, with not window managers, nothing.

    So you need to add these lines to /etc/gdm/custom.conf:

    AutomaticLoginEnable=true
    AutomaticLogin=[username]

    (replacing [username] with your username of course. And to get chrome to start up create a script ~/start_chrome.sh:

    #!/bin/sh
    /opt/google/chrome/chrome http://www.mystartsite.com

    and make it executable:

    chmod 755 ~/start_chrome.sh

    then edit ~/.xsession (or create it if it’s not already there) and add

    #!/bin/sh
    /home/[username]/start_chrome.sh

    Just in case make that file executable too

    chmod 755 ~/.xsession
  9. Ok, you’re set. Reboot. Hopefully you’ll end up in X without any login prompts in chrome loading your favourite page. Now you wont have any menus or whatever – so to break out into a shell press Ctrl+Alt+F1  (add fn if on a Mac). (This always works on X btw). Ok, now back in the shell. Be sure to remove any temporary files which are no longer needed, as space on a CD is limited. A classic example is downloaded package files, which can be cleaned out using:
    sudo aptitude clean
    sudo rm -rf /tmp/* ~/.bash_history
    sudo rm /etc/hosts
    sudo rm /var/lib/dbus/machine-id
  10. Ok, so assuming you’re happy with your setup, to create the actual .iso image, you just have to do:
    sudo remastersys backup livecd.iso

    It should place the file livecd.iso in /home/remastersys/remastersys/

  11. You could try and burn that .iso to a real CDROM by linking up your real drive to the virtual machine with VirtualBox.
    cdrecord dev=/dev/cdrom livecd.iso

    I didn’t try that. Instead, to get that file out of the virtual machine I just used scp and uploaded it to antoher ssh server of mine and then downloaded it back to my Mac and just used DiskUtil to burn the CD. Now that is clearly stupid. A better way might be to mount another, real, drive inside the virtual machine or a USB stick. Again I didn’t try this but it seems very reasonable. Even better would be to have a way to mount the VirtualMachine’s drive (it’s a .vdi file) somehow on the Mac but I wasn’t able to find a way to actually do that. Seems like it should be no brainer. Anyway. You can also test you .iso by creating another virtual machine on VirtualBox and shoving the new .iso in the virtual CD drive. I recommend doing that before burning a physical CD since it will save you time if something messed up. Anyway, all this was a lot of fun and a very neat way to deal with readymade systems.

    Another cool thing would be to burn the iso to a thumbdrive. I had some success in making bootable thumbdrives using a windows machine. I tried doing the same on a Mac and it just would not boot anywhere even though the filesystems etc were set up ok on the drive. Having the bootable system on the drive is superior in the sense that any post-boot changes you make (like cookies etc). will be remembered on the next boot, while they’re totally lost on the CD.

Links:

An alternative way (more manual) to ccreate the .iso:

https://help.ubuntu.com/community/LiveCDCustomization

http://www.remastersys.com/ubuntu.html

, ,
